IB Physics SL A.2.20 Collisions and Conservation of Energy

Practise distinguishing elastic and inelastic collisions using momentum, kinetic energy and rebound evidence.

Syllabus
First assessment 2025
Course
Physics SL
Level
SL

Exam points

  • Use momentum and kinetic-energy evidence to classify elastic and inelastic collisions.
  • Analyse rebound and sticking outcomes in one-dimensional collisions.

A.2.20—Elastic and inelastic collisions question 1

[Maximum number: 2]

B3. This question is in two parts. Part 1 is about a collision. Part 2 is about electric current and resistance.
Part 1 A collision
Two identical blocks of mass 0.17 kg and length 0.050 m are travelling towards each other along a straight line through their centres as shown below. Assume that the surface is frictionless.

Figure for Question A.2.20—Elastic and inelastic collisions question 1 — IB Physics SL

The initial distance between the centres of the blocks is 0.900 m and both blocks are moving at a speed of 0.18 m s10.18 \mathrm{~m} \mathrm{~s}^{-1} relative to the surface.

As a result of the collision, the blocks reverse their direction of motion and travel at the same speed as each other. During the collision, 20 % of the kinetic energy of the blocks is given off as thermal energy to the surroundings.

State and explain whether the collision is elastic or inelastic.
