Edexcel IGCSE Biology cloning

Use cloning evidence to describe plant and mammal cloning procedures, then calculate or interpret success rates from embryo-transfer data.

Syllabus
First assessment 2019
Course
Biology 4BI1

Exam points

  • Complete cloning passages with explant, clone, agar, embryo, uterus or surrogate terms.
  • Describe plant or mammal cloning stages from procedures, diagrams or passage evidence.
  • Calculate and interpret cloning success data, including embryo-transfer percentages.

(d) Cloning question 1

[Maximum number: 9]

Micropropagation is used to produce plant clones.
The process involves growing explants in vitro.

Question (a)

(a)

State what is meant by the term in vitro.

[ 1 ]

Question (b)

(b)

The explants grow new roots and shoots.

A student investigates the effect of pH on the growth of new shoots.
The table shows the student's results.

Table for Question (b) — Edexcel IGCSE Biology
[ 6 ]

Question (i)

(i)

Describe a procedure the student could use to obtain explants and produce these results.

[ 6 ]

Question (c)

(c)

Give two benefits of using micropropagation to produce new plants rather than using seeds.

1

2

[ 2 ]

(d) Cloning question 2

[Maximum number: 3]

Read the passage below. Use the information in the passage and your own knowledge to answer the questions that follow.

Supercharging plants to reduce global warming

The proportion of carbon dioxide in the atmosphere has increased in the last 100 years. In 2020, a mass of 727 gigatonnes of carbon dioxide was released into the atmosphere from natural processes, along with a mass of 37 gigatonnes from human activities. Scientists have estimated that plants naturally remove a mass of 746 gigatonnes of carbon dioxide from the atmosphere every year. The difference between what is removed and what is released causes atmospheric carbon dioxide to rise every year. Carbon dioxide is a greenhouse gas, and a significant rise will cause global warming.

To help solve the problem of rising concentrations of atmospheric carbon dioxide, scientists are planning to produce transgenic, supercharged plants that can remove atmospheric carbon dioxide and store it in their roots. The scientists estimate that if these plants can be developed, the plants could remove a mass of carbon dioxide equivalent to 50% of the emissions from human activities.

Coastal plants that have their roots in seawater contain a substance called suberin in the cell walls of the outer layer of the roots. Suberin is a waterproof substance that contains a high proportion of carbon atoms. Suberin is decomposed very slowly so remains in the soil for a long time.

The photograph shows a coastal plant called a mangrove.

Figure for Question (d) Cloning question 2 — Edexcel IGCSE Biology

To produce the supercharged plants, scientists intend to take the gene that codes for high suberin production from a coastal plant and insert it into crop plants. The crop plants used are perennial plants. Perennial plants live for many years rather than dying each winter. The transgenic crops would take in large amounts of carbon dioxide and use the carbon atoms to make suberin. The carbon would then be locked up and stored as suberin in the roots. After successfully producing one plant, they will use micropropagation rather than pollination to produce others.

These supercharged crop plants may have other uses. Suberin in roots helps to make them tolerant to soil with a high salt concentration, helping to produce higher crop yields in areas that have difficult growing conditions.

Give three reasons why the scientists use micropropagation to reproduce the transgenic crop plants (lines 24 to 25).

1

2

3

(d) Cloning question 3

[Maximum number: 6]

Read the passage below.
Use the information in the passage and your own knowledge to answer the questions that follow.

Toystory

Toystory is a bull who was born in 2001. The photograph shows Toystory.

Figure for Question (d) Cloning question 3 — Edexcel IGCSE Biology

In the world of dairy farming Toystory is a famous bull. He fathered 500000 offspring but did not mate with any cows. He was able to father so many offspring because his semen was collected and then used to fertilise cows using artificial insemination.

Toystory's mother was a high milk producer and his father was a popular bull. He was sold for $ 4000 by his owner to a specialist breeding company called Genex.

Genex started to collect semen from Toystory when he was four years old. The semen is carefully collected, using a teaser animal and an artificial rubber vagina.

The semen is divided into many separate samples. These samples are put in small straws and frozen in liquid nitrogen. The straws can then be sold and sent to dairy farmers around the world to inseminate their cows. A total of 2.4 million samples of semen from Toystory was sold in more than 50 countries around the world.

Toystory's reputation grew as the offspring he fathered went on to be high milk producers. His semen straws sold for over $ 60 each. Bull semen can now be sold as sexed or unsexed samples, with sexed samples being more expensive to purchase.

Toystory was highly valued because his offspring produced large quantities of milk of a desired composition. His semen was effective at getting cows pregnant, his daughters gave birth easily and were strong. He had a rare mix of fertility, genetics and appearance.

25 One of his daughters sold for $ 300000 in 2009. His record number of offspring is unlikely to be beaten. This is because bulls are often retired earlier as new genetic advances are discovered.

Question (a)

(a)

Scientists are now using cloning to produce animals.

Describe the stages that are required to clone a bull.

[ 4 ]

Question (b)

(b)

Give two advantages of using cloning rather than selective breeding to produce offspring.

1

2

[ 2 ]
