CAIE IGCSE Mathematics Extended E2.12 Diffe…ation

[Maximum number: 5]

Figure for Question 1 — CAIE IGCSE Mathematics Extended

The diagram shows a sketch of $y=18+5 x-2 x^{2}$ .

(a)

Differentiate 18+5 x-2 x^2.

[ 2 ]

(b)

Find the coordinates of the point on y=18+5 x-2 x^2 where the gradient is 17 .

[ 3 ]

(-3,-15)
B2FT for x=-3
OR M1 for their (b) = 17
M1dep for correct substitution of their x into $18+5x-2x^2$ shown

[Maximum number: 5]

Figure for Question 2 — CAIE IGCSE Mathematics Extended

\mathrm{f}(x)=x(x+2)(x-3)

A is the point (1,-6).

The tangent to the graph of y=f(x) at A meets the y-axis at B.
Find the coordinates of B.
(

[Maximum number: 8]

(a)

A curve has equation $y=4 x^{3}-3 x+3$ .

[ 8 ]

(i)

Find the coordinates of the two stationary points.

(___, ___) and (___, ___)

[ 5 ]

$\left(-\frac{1}{2},4\right)$ and $\left(\frac{1}{2},2\right)$
B2 for $12x^2-3=0$ , or B1 for $12x^2$ or -3.
M1 for derivative =0 or $\frac{dy}{dx}=0$ .
B1 for $x=-\frac{1}{2}$ and $x=\frac{1}{2}$ , or one coordinate pair correct.

(ii)

Determine whether each of the stationary points is a maximum or a minimum. Give reasons for your answers.

[ 3 ]

$\begin{aligned} \left(-\frac{1}{2},4\right)&\text{ maximum with reason}\\ \left(\frac{1}{2},2\right)&\text{ minimum with reason} \end{aligned}$
B2 for one correct with reason, or M1 for a correct attempt such as second derivative, gradients, or sketch.

[Maximum number: 3]

The table shows some values for $y=x^{3}+4 x^{2}-4$ .

Table for Question 4 — CAIE IGCSE Mathematics Extended

(a)

Draw the tangent to the graph at the point (1,1).

[ 1 ]

(b)

Use your tangent to estimate the gradient of the curve at the point (1,1).

[ 2 ]

[Maximum number: 2]

Figure for Question 5 — CAIE IGCSE Mathematics Extended

The diagram shows a sketch of $y=18+5 x-2 x^{2}$ .

Differentiate 18+5 x-2 x^2.

[Maximum number: 3]

A curve has equation $y=4 x^{3}-3 x+3$ .

Determine whether each of the stationary points is a maximum or a minimum. Give reasons for your answers.

$\begin{aligned} \left(-\frac{1}{2},4\right)&\text{ maximum with reason}\\ \left(\frac{1}{2},2\right)&\text{ minimum with reason} \end{aligned}$
B2 for one correct with reason, or M1 for a correct attempt such as second derivative, gradients, or sketch.
