CAIE A-Level Mathematics AS 1.4.2 Arc Length and Sector Area Questions

Practise applying s = rθ and A = ½r²θ to sectors and compound figures, using triangle geometry to obtain unknown angles, radii, perimeters and segment areas.

Syllabus
2028–2030
Course
Mathematics 9709
Level
AS

Exam points

  • Calculate arc length and sector area using s = rθ and A = 1/2 r²θ, with angles in radians.
  • Use arc and sector formulae with triangle geometry to find unknown angles, radii, lengths, perimeters or areas in composite circular figures.
  • Form and solve equations from stated arc-length, sector-area or perimeter conditions to determine an unknown radius or angle.

CAIE A-Level Mathematics AS 1.4.2 Arc Length and Sector Area Questions question 1

[Maximum number: 6]
Figure for Question CAIE A-Level Mathematics AS 1.4.2 Arc Length and Sector Area Questions question 1 — CAIE A-Level Mathematics AS
Figure for Question CAIE A-Level Mathematics AS 1.4.2 Arc Length and Sector Area Questions question 1 — CAIE A-Level Mathematics AS

The diagram shows a sector of a circle with centre C. The radii C A and C B each have length r cmr \mathrm{~cm} and the size of the reflex angle A C B is θ\theta radians. The sector, shaded in the diagram, has a perimeter of 65 cm and an area of 225 cm2225 \mathrm{~cm}^{2}.

Question (a)

(a)

Find the values of r and θ\theta.

[ 4 ]

Question (b)

(b)

Find the area of triangle A C B.

[ 2 ]
