AP Physics C E and M 13.6 LC Circuits Overview
Describe capacitor-inductor circuits through energy exchange, maximum current, oscillatory charge, and simple harmonic motion.
- Syllabus
- Effective Fall 2025
- Course
- AP Physics C: Electricity & Magnetism
Describe capacitor-inductor circuits through energy exchange, maximum current, oscillatory charge, and simple harmonic motion.
E\&M. 2.
The circuit represented above contains a 9.0 V battery, a 25 mF capacitor, a 5.0 H inductor, a 500Ω resistor, and a switch with two positions, S1 and S2. Initially the capacitor is uncharged and the switch is open.
In experiment 2 the capacitor is again uncharged when the switch is closed to position S1 at time t1. The switch is then moved to position S2 at time t2 when the magnitude of the charge on the capacitor plate is 105 mC, allowing electromagnetic oscillations in the LC circuit.
Calculate the energy stored in the capacitor at time t2.
Calculate the maximum current that will be present during the oscillations.
Calculate the time rate of change of the current when the charge on the capacitor plate is 50 mC.

2 points
For substituting correct values into a correct expression 1 point
For example, UC=21(25×10−3 F)(105×10−3C)2
For a consistent answer with correct units 1 point
UC=0.22 J
2 points
The maximum current occurs when there is no charge on the capacitor and all the energy is stored in the inductor.
The total energy is the energy that was stored in the capacitor at time t2.
For a correct expression of energy conservation
Substituting the given value for L and the value of UC determined in part (b) i
For an answer with units consistent with previous work
3 points
For a correct application of the loop rule
For a correct numerical answer obtained from a correct procedure, with or without the negative sign
For the correct units on a calculated answer
